Protein solubility in KOH - A key factor for feed quality and animal welfare
Protein solubility in potassium hydroxide (KOH) is a decisive quality parameter for protein-rich feedstuffs. Particularly in the case of soybeans, a central protein source in animal nutrition, this value provides information on the digestibility and physiological benefits of the protein. As soybeans contain not only high-quality amino acids but also antinutritive factors - natural or synthetic compounds in food or feed that can inhibit or impair the utilization of nutrients in the body - targeted thermal processing is necessary. Processes such as toasting, steaming or extrusion improve the protein structure and reduce antinutritive ingredients. The protein solubility in KOH serves as a measure of the efficiency of these processing methods.
KOH protein solubility | Assessment of the protein quality |
---|---|
< 70% | Overheating damage (proteins denature, are less soluble and less digestible) |
78-85% | Optimal |
> 85% | Possible inadequate heat treatment (antinutritive substances such as trypsin inhibitors are not destroyed, poorer digestibility)[i] |
Source: Van Eys J.E., Offner A., Bach A. Manual of Quality Analyses for Soybean Products in the Feed Industry. 2nd ed. American Soybean Association; Brussels, Belgium: 2004
The test is based on the determination of the soluble fraction of the protein in a 0.2% KOH solution. Higher values indicate good availability and digestibility, while lower values indicate overheating or inadequate processing. This indicator is particularly important in the animal feed industry to assess the quality of soy extraction meal and other protein sources. Targeted laboratory control can maximize nutrient intake and optimize feed conversion.
Another advantage of laboratory control is that tests on animals can be reduced or even avoided altogether. Laboratory analysis makes it possible to ensure the quality and digestibility of the feed in advance - a significant step towards greater animal welfare and sustainability in feed production.
However, protein solubility in KOH goes beyond quality control: in compound feed calculation, it serves as a solid basis for ration optimization. Good solubility is directly related to digestibility - a key factor for the growth performance and health of livestock. Combined with indicators such as trypsin inhibitor activity (TIA) or urease activity, it provides a comprehensive picture of protein quality and processing intensity.
Standardized methods such as ISO 14244 and VDULFA Method Book Volume III 20.2 guarantee a high reproducibility of the results. The analysis is usually carried out using the Kjeldahl or Dumas method, which precisely quantify the nitrogen content of the soluble protein components. This means that protein solubility in KOH is not only an indispensable tool for quality assurance, but also makes a significant contribution to optimizing nutrient supply and promoting animal welfare.
The method - Kjeldahl application
Sample preparation and weighing
The soy flour is ground through a sieve and then 1.5 g is weighed and placed in a beaker. 75 ml of potassium hydroxide solution is added and the sample is stirred for 20 minutes at minimum speed. The liquid is then centrifuged in a centrifuge tube for 10 minutes at a relative acceleration of 800 g or alternatively filtered for between 20 - 60 minutes. Immediately before weighing in, the sample is thoroughly shaken again. 25 ml aliquots of the filtrate are added to the tube for digestion. Each aliquot then corresponds to 0.5 g of the originally ground sample.
- Application note: The particle size of the sample influences the analysis result.
- Application note: If the fat content is more than 5%, the fat must be removed by cold extraction
Digestion
The sample is placed in a digestion tube with a KJELCAT tablet (CU 5.0 g K2SO4 x 5 H2O) and sulphuric acid (20 ml). The sample is then digested using the parameters specified in the applications for the digestion devices (KJELDATHERM or TURBOTHERM). The acid vapours are neutralized using a gas scrubber (TURBOSOG or VACUSOG).
- Application note: The gas scrubber should remain switched on for approx. 30 minutes after removing the insert rack.
Distillation and titration
After the sample has cooled down, steam distillation is carried out. For the titration, 3-4 drops of the indicator solution are added to the sample solution and titrated with the standard solution until the color changes from green to violet. No indicator solution is required when determining the end point using a pH electrode.
Blank value
To determine the blank value, carry out the analysis (digestion + distillation + titration) using only the specified chemicals and 1 g of sucrose instead of the sample. The consumption of the standard solution must be taken into account in the calculation
Calculation
Analytical results for various sample types from ring test tests (Kjeldahl)
Sample type | Measured value | Result [%] | Mean value Ring test[%] | Repeatability s.d. | z-Score |
---|---|---|---|---|---|
Organic sunflower seeds | Crude protein (N x 6,25) | 23,32 | 23,51 | 0,73 | -0,26 |
Organic sunflower seeds | Protein solubility in KOH | 86,70 | 93,25 | 5,69 | -1,15 |
Rapeseed cake | Crude protein (N x 6,25) | 33,61 | 33,63 | 0,5 | -0,04 |
Rapeseed cake | Protein solubility in KOH | 90,00 | 91,35 | 3,06 | -0,44 |
Fava bean | Crude protein (N x 6,25) | 30,11 | 29,87 | 0,52 | 0,45 |
Fava bean | Protein solubility in KOH | 91,40 | 88,33 | 6,8 | 0,45 |
Compound feed | Crude protein (N x 6,25) | 17,22 | 17,34 | 0,66 | -0,18 |
Compound feed | Protein solubility in KOH | 79,40 | 79,54 | 6,15 | -0,02 |
Raw soybean | Crude protein (N x 6,25) | 41,31 | 41,63 | 0,6 | -0,53 |
Raw soybean | Protein solubility in KOH | 94,40 | 89,62 | 7,5 | 0,64 |
The method - Dumas application
Sample preparation
The soy flour is ground through a sieve and then 1.5 g is weighed and placed in a beaker. 75 ml of potassium hydroxide solution is added and the sample is stirred for 20 minutes at minimum speed. The liquid is then centrifuged in a centrifuge tube for 10 minutes at a relative acceleration of 800 g or alternatively filtered - duration between 20 - 60 minutes.
- Application note: The particle size of the sample influences the analysis result.
- Application note: If the fat content is more than 5%, the fat must be removed by cold extraction.
Weighing
DumaFoil tin foil is tared and about 20 mg of superabsorbent (ratio 1:10) is added. The balance is tared again and about 200 mg of filtrate is added with a syringe. After the sample has reacted with the superabsorber, the aluminum foil is closed and placed in the transfer tray.
Calibration
The selected calibration must cover the working range. When using a recommended weight of the sample, calibration with a THAM solution of 0.5 % N to 2.5 mg N is sufficient.
Calculation
Analytical results for different sample types from ring test tests (Kjeldahl) compared to Dumas
Sample type | Measured value | Result - Dumas [%] | Mean value ring test - Kjeldahl [%] |
---|---|---|---|
Organic sunflower seeds | Crude protein (N x 6,25) | 21,45 | 23,51 |
Organic sunflower seeds | Protein solubility in KOH | 91,40 | 93,25 |
Rapeseed cake | Crude protein (N x 6,25) | 30,65 | 33,63 |
Rapeseed cake | Protein solubility in KOH | 86,86 | 91,35 |
Fava bean | Crude protein (N x 6,25) | 26,98 | 29,87 |
Fava bean | Protein solubility in KOH | 93,65 | 88,33 |
Compound feed | Crude protein (N x 6,25) | 15,59 | 17,34 |
Compound feed | Protein solubility in KOH | 76,88 | 79,54 |
Raw soybeans | Crude protein (N x 6,25) | 37,10 | 41,63 |
Raw soybeans | Protein solubility in KOH | 93,32 | 89,62 |
